Sinotruk HOWO 14m³-18m³ compressed garbage truck
2024-10-07 09:54:11 Source：CLW
Sinotruk HOWO 14m³-18m³ compressed garbage truck
Chassis configuration:
1. Engine: Weichai 240hp, WP4.6NQ240E62
2.Transmission type: Howo 8 speed gear
3.Tyre: 10.00R20 steel wire tire, 6 with a spare
4.Wheelbase:4500/4700/5100mm
5.Other:Airbag seats, automatic electronic control constant temperature air conditioning, electric doors and windows
Central control room, remote key, ABS, adjustable headlights, electric glass remote control. High end sedan configuration
| Product Name |
Sinotruk HOWO 14m³-18m³ compressed garbage truck |
| Driving Type |
4x2 |
| Garbage container volume(cbm) |
14-18 |
| Rated payload weight(kg) |
7170,7105,6970,6905,6870,6805,6670,6605,6370,6305(Kg) |
| Wheelbase(mm) |
4500/4700/5100mm |
| Overall Dimension(mm) |
8900,9100,9300,9600,9800,8950,9150,9650×2550×3250(mm) |
| Engine brand & model |
Weichai 240hp, WP4.6NQ240E62 |
| Axle Quantity |
2 |
| Transmission Type |
Howo 8 speed gear |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
10.00R20 steel wire tire, 6 with a spare |
| Cab |
Heavy truck 2350mm cab with 700mm sleeper, four point suspension airbag seat, the largest cab and sleeper on the same platform! |
| Garbage container material |
Manganese steel and high-strength steel |
| Standard configuration |
1-The upper part is made of high-quality high-strength steel plate to create a box with a capacity of approximately 18 cubic meters, 2- Double sewage tanks on the tail side, one sewage outlet on the side, and a push plate and scraper to complete the garbage compression function, |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Sinotruk HOWO 14m³-18m³ compressed garbage truck
Compressed garbage truck: composed of a sealed
garbage bin, hydraulic system, and operating system, it compresses and pours
itself. During the compression process, all the sewage enters the sewage tank,
which completely solves the problem of secondary pollution in garbage
transportation.
1-The upper part is made of high-quality high-strength steel plate to create a box with a capacity of approximately 18 cubic meters,
2- Double sewage tanks on the tail side, one sewage outlet on the side, and a push plate and scraper to complete the garbage compression function,
3- Wanye gear oil pump (double pump), Hepres hydraulic cylinder, Zhongmei multi way directional valve,
4. Tail flip rack, capable of hanging 2 240L trash cans simultaneously,
5-Equipped with wireless remote control, CAN/PLC bus control operation, compaction valve, and night work light.
6-The tail can be equipped with pneumatic sealing cover/triangular bucket/large landing bucket/swing arm device
Product parameters
