Sinotruk HOWO 6m³ underground compressed garbage truck

5.Other: Color screen instrument panel, reflective vest, National VI emission monitoring terminal, steel air cylinder, adjustable headlights, air dryer, Bluetooth module, front and rear axle wear alarm device, central locking and electric doors and windows+remote key; Left/right L-shaped new national standard rearview mirror; Dynamic rotation with air conditioning; Fuel urea integrated system (80L+14L); ABS, air brake

Compressed garbage truck: composed of a sealed garbage bin, hydraulic system, and operating system, it compresses and pours itself. During the compression process, all the sewage enters the sewage tank, which completely solves the problem of secondary pollution in garbage transportation.

The underground compressed garbage truck is a vehicle that can enter the basement to clean up garbage.

Installation configuration of Sinotruk HOWO 6m³ underground compressed garbage truck

1-The box has a capacity of approximately 6 cubic meters and is made of manganese steel material. The rear package is made of high-strength steel,

2-Jiashan power take-off, pump valve type: iron shell single pump, integral valve;

3-Flip style: National standard 240L flip bucket rack, with bearings fixed on both sides of the flip base,

4- Fujian Shanyou Oil Cylinder, CAN Fuli Guangda Electronic Control System,

The driver's control panel has throttle adjustment function and fault warning function, and the rear is equipped with an Eaton operation box (manual electronic control button operation on the passenger side, emergency stop switch and loading/unloading switch on the driver's side),

6- Equipped with Kawagoe wireless remote control and pressure valve;

7. The body color shall be made according to the requirements of the purchaser,

8- Other configurations according to compressed garbage truck standards

Product parameters

Product Name	Sinotruk HOWO 6m³ underground compressed garbage truck
Driving Type	4x2
Garbage container volume(cbm)	6
Rated payload weight(kg)	/
Wheelbase(mm)	2800
Overall Dimension(mm)	7340×2350×2800
Engine brand & model	Weichai 140hp, WP2.3Q140E62
Axle Quantity	2
Transmission Type	5 forward gears and 1 reverse gear
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	6.50R16 12PR vacuum tire, 6 with a spare
Cab	1760/low top single row, all inclusive interior, fabric seats
Garbage container material	Manganese steel and high-strength steel
Standard configuration	The box has a capacity of approximately 6 cubic meters and is made of manganese steel material. The rear package is made of high-strength steel,
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
