6X4 Sinotruk HOWO 16 ton foam fire truck
2024-10-07 09:54:11 Source：CLW
6X4 Sinotruk HOWO 16 ton foam fire truck
Chassis configuration:
1. Engine: MC11.46-61, Sinotruk 460hp
2.Transmission type: 10-speed gearbox
3.Tyre: 385/65R22.5/315/80R22.5 18PR,385/65R22.5/12.00R20 18PR, 10 +1 spare,
4.Wheelbase:4300+1400(mm)
5.Other: Sinotruk HOWO double row cab
Installation configuration:
1- The effective volume of the tank is 16 cubic meters, the water tank is 12 cubic meters, and the foam tank is 4 cubic meters,
2- The water tank is made of high-quality carbon steel with anti-corrosion treatment inside, and the foam tank is made of 304 stainless steel,
3-CB10/60 atmospheric pressure fire pump, West PS50 fire monitor, with a range of ≥ 68 meters, can be used for rapid water replenishment of tanks, forest fire fighting series water supply and fire extinguishing operations,
4- Suitable for government fire rescue teams, urban main battle fire rescue, full-time fire teams, power companies, substations, chemical enterprises
| Product Name |
6X4 Sinotruk HOWO 16 ton foam fire truck |
| Driving Type |
6X4 |
| Total weight（Kg) |
27600(Kg) |
| Curb weight(kg) |
14950(Kg) |
| Rated weight(kg) |
12200(Kg) |
| Wheel base(mm) |
4300+1400(mm) |
| Overall dimension(mm) |
9680×2550×3620(mm) |
| Engine brand & model |
MC11.46-61, Sinotruk 460hp |
| Displacement(L)/Power(kw) |
10.5L/341KW |
| Axle Quantity |
3 |
| Transmission Type |
10-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
air brake |
| Tire Spec. & size |
385/65R22.5/315/80R22.5 18PR,385/65R22.5/12.00R20 18PR, 10 +1 spare |
| Cab |
Sinotruk HOWO double row cab |
| Extinguishing Media |
water/foam/dry-powder |
| Tank material |
High quality carbon steel for water tank, 304 stainless steel for foam tank |
| Tank volume（L） |
12cbm water tank+4cbm foam tank |
| Configuration and performance |
Full power sandwich power take-off, CB10/60 atmospheric pressure fire pump, West PS50 fire monitor, with a range of ≥ 68 meters, |
| Onboard equipment |
Onboard equipment Fire hose, water injection hose, DC water gun, multifunctional water gun, dry powder fire extinguisher, water collector, water separator, suction pipe wrench, rubber hammer, protective belt bridge, above ground fire hydrant wrench, underground fire hydrant wrench, water hose strap, water hose hook, fire axe, fire suction pipe, suction pipe filter, reducer interface |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
6X4 Sinotruk HOWO 16 ton foam fire truck
A fire engine, also known as a fire truck,
refers to a vehicle designed and manufactured according to needs, suitable for
firefighters to use, equipped with various fire-fighting equipment or agents,
for firefighting, auxiliary firefighting, or firefighting rescue. It is the
main tool for firefighting and is also the most basic mobile firefighting
equipment.
Foam fire truck: foam fire truck and water tank fire truck are basically the same, but the difference is that the material used by foam fire truck to extinguish fire is foam, while the water tank fire truck uses water. Foam fire truck is mainly equipped with fire pump, water tank, foam liquid tank, foam mixing system, foam gun, monitor and other fire-fighting equipment, which can fight fire accidents independently. It is especially suitable for fighting oil fire accidents such as oil and its products, and can also supply water and foam mixture to the fire site. It is a necessary fire fighting vehicle for petrochemical enterprises, oil terminals, airports and urban professional fire brigades.
Product parameters
