Sinotruk HOWO 16cbm foam fire-fighting vehicle
2024-10-07 09:54:11 Source：CLW
Sinotruk HOWO 16cbm foam fire-fighting vehicle
Chassis configuration:
1. Engine: MC11.44-60，440hp
2.Transmission type: 9-speed gearbox or 12-speed gearbox
3.Tyre: 385/65R22.5/12.00R20,10 + 1 spare
4.Wheelbase:4600+1400(mm)
5.Other: Flat head, four door, modified double row (optional rear air respirator backrest), power steering, clutch assist, electric doors and windows, central locking, air conditioning, air brake:
Installation configuration:
Fire pump model: CB10/80
Fire monitor model: PL8/48
Fire monitor flow rate: 48L/S
Fire monitor range: foam ≥ 65m, water ≥ 70m
| Product Name |
Sinotruk HOWO 16cbm foam fire-fighting vehicle |
| Driving Type |
6X4 |
| Total weight（Kg) |
31400(Kg) |
| Curb weight(kg) |
14800(Kg) |
| Rated weight(kg) |
16150(Kg) |
| Wheel base(mm) |
4600+1400(mm) |
| Overall dimension(mm) |
9920×2550×3680(mm) |
| Engine brand & model |
MC11.44-60，440hp |
| Displacement(L)/Power(kw) |
6.2L/169KW |
| Axle Quantity |
3 |
| Transmission Type |
9-speed gearbox or 12-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
air brake |
| Tire Spec. & size |
385/65R22.5/12.00R20,10 + 1 spare |
| Cab |
Flat head, four door, modified double row (optional rear air respirator backrest), power steering, clutch assist, electric doors and windows, central locking, air conditioning, air brake: |
| Extinguishing Media |
water/foam/dry-powder |
| Tank material |
Carbon steel or stainless steel and aluminum alloy plate |
| Tank volume |
12.5m³ water tank+3.5m³ foam |
| Configuration and performance |
Fire pump model: CB10/80 Fire monitor model: PL8/48 Fire monitor flow rate: 48L/S Fire monitor range: foam ≥ 65m, water ≥ 70m |
| Onboard equipment |
Onboard equipment Fire hose, water injection hose, DC water gun, multifunctional water gun, dry powder fire extinguisher, water collector, water separator, suction pipe wrench, rubber hammer, protective belt bridge, above ground fire hydrant wrench, underground fire hydrant wrench, water hose strap, water hose hook, fire axe, fire suction pipe, suction pipe filter, reducer interface |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Sinotruk HOWO 16cbm foam fire-fighting vehicle
A fire engine, also known as a fire truck,
refers to a vehicle designed and manufactured according to needs, suitable for
firefighters to use, equipped with various fire-fighting equipment or agents,
for firefighting, auxiliary firefighting, or firefighting rescue. It is the
main tool for firefighting and is also the most basic mobile fire fighting
equipment.
Foam fire-fighting vehicle: foam fire-fighting vehicle and water tankfire-fighting vehicleare basically the same, but the difference is that the material used byfoam fire-fighting vehicleto extinguish fire is foam, while the water tankfire-fighting vehicleuses water.Foam fire-fighting vehicleis mainly equipped with fire pump, water tank, foam liquid tank, foam mixing system, foam gun, monitor and other fire-fighting equipment, which can fight fire accidents independently. It is especially suitable for fighting oil fire accidents such as oil and its products, and can also supply water and foam mixture to the fire site. It is a necessary fire fighting vehicle for petrochemical enterprises, oil terminals, airports and urban professional fire brigades.
Product parameters
