FOTON Xiangling M1 hanging bucket garbage truck
2024-10-07 09:54:11 Source：CLW
Chassis configuration:
1. Engine: DAM16KR, 122kw
2.Transmission type: 5-speed gearbox
3.Wheelbase:3070,3170(mm)
4.Tyre:175R14LT 8PR, 6+1 spare
5.Other:FOTON Xiangling M1 cab
| Product Name |
FOTON Xiangling M1 hanging bucket garbage truck |
| Driving Type |
4×2 |
| Gross vehicle weight(Kg) |
2995(Kg) |
| Curb weight(Kg) |
2000(Kg) |
| Rated weight(kg) |
865(Kg) |
| Wheelbase(mm) |
3070,3170(mm) |
| Overall Dimension(mm) |
4775,4875×1730×2320(mm) |
| Engine |
DAM16KR, 122kw |
| Axle Quantity |
2 |
| Transmission Type |
5-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Tire Spec. & size |
175R14LT 8PR, 6+1 spare |
| Cab |
FOTON Xiangling M1 cab |
| Volume(m³) |
/ |
| Tank body |
Reinforced square tank body, Q710 high-strength steel |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
FOTON Xiangling M1 hanging bucket garbage truck
Hanging bucket garbage truck, also known as self loading and unloading garbage truck, is mainly used for transporting various types of garbage in various environmental sanitation, municipal and large-scale industrial and mining departments. It can also transport bulk building materials such as ash, sand, stone, soil, etc. It can also transport ore or coal in mines or coal mines. It consists of a sealed garbage bin, hydraulic system, and operating system. The lifting oil cylinder (2 pieces) garbage bin can be hung up and down by itself, and the working cycle time of up and down is ≤ 50S.
