Sinotruk Howo 8X4 23-ton Water Tank Fire Truck
2024-10-07 09:54:11 Source：CLW
Chassis configuration:
(1)Engine: D10.34-50, Sinotruk 340HP
(2)Wheelbase: 1800+4600+1350,1800+4575+1400,2150+4600+1350,2150+4575+1400,2150+4300+1350,2150+4275+1400(mm)
(3)Transmission Type:12-speed gearbox
(4)Tire models: 385/65R22.5/315/80R22.5,385/65R22.5/12.00R20,385/65R22.5/12.00-20, 12+1 spare
(5)Other: Sinotruk Howo cab
| Product Name |
Sinotruk Howo 8X4 23-ton Water Tank Fire Truck |
| Driving Type |
8X4 |
| Total weight（Kg) |
41000(Kg) |
| Curb weight(kg) |
17300(Kg) |
| Rated weight(kg) |
23550(Kg) |
| Wheel base(mm) |
1800+4600+1350,1800+4575+1400,2150+4600+1350,2150+4575+1400,2150+4300+1350,2150+4275+1400(mm) |
| Overall dimension(mm) |
11900×2500×3635(mm) |
| Engine brand & model |
D10.34-50, Sinotruk 340HP |
| Axle Quantity |
4 |
| Transmission Type |
12-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
air brake |
| Tire Spec. & size |
385/65R22.5/315/80R22.5,385/65R22.5/12.00R20,385/65R22.5/12.00-20, 12+1 spare |
| Cab |
Sinotruk Howo cab |
| Extinguishing Media |
water/foam/dry-powder |
| Tank material |
Carbon steel or stainless steel and aluminum alloy plate |
| Tank volume |
23m³ water tank |
| Onboard equipment |
Onboard equipment Fire hose, water injection hose, DC water gun, multifunctional water gun, dry powder fire extinguisher, water collector, water separator, suction pipe wrench, rubber hammer, protective belt bridge, above ground fire hydrant wrench, underground fire hydrant wrench, water hose strap, water hose hook, fire axe, fire suction pipe, suction pipe filter, reducer interface |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
4x2 Dongfeng 2 ton water tank fire truck
Water tank fire truck is a vehicle specifically used for firefighting or other emergency rescue purposes.
Water tank fire truck, also known as fire truck, is a vehicle specifically used for firefighting or other emergency rescue purposes.
A water tank fire truck refers to a vehicle equipped not only with fire pumps and equipment, but also with large capacity water storage tanks, water guns, water cannons, etc. Water and firefighters can be transported to the fire scene for independent firefighting.
