Dongfeng D6 2.5 ton water tank fire truck
2024-10-07 09:54:11 Source：CLW
Dongfeng D6 2.5 ton water tank fire truck
Chassis configuration:
1. Engine: Q23-115E60，Quanchai 115hp
2.Transmission type: 5-speed gearbox
3.Tyre: 7.00R16,7.00R16LT 14PR,6 + 1 spare
4.Wheelbase:3800,3950,4050,4100,4400,3600,4700(mm)
5.Other: Flat head, four door double row cab
Installation configuration:
CB10/20 fire pump, PS8/20W fire monitor.
| Product Name |
Dongfeng D6 2.5 ton water tank fire truck |
| Driving Type |
4X2 |
| Total weight（Kg) |
6800(Kg) |
| Curb weight(kg) |
4325(Kg) |
| Rated weight(kg) |
2100(Kg) |
| Wheel base(mm) |
3308(mm) |
| Overall dimension(mm) |
5990×2000×2660(mm) |
| Engine brand & model |
Q23-115E60，Quanchai 115hp |
| Displacement(L)/Power(kw) |
2.3L/85KW |
| Axle Quantity |
2 |
| Transmission Type |
5-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
air brake |
| Tire Spec. & size |
7.00R16,7.00R16LT 14PR,6 + 1 spare |
| Cab |
Flat head, four door double row cab |
| Extinguishing Media |
water/foam/dry-powder |
| Tank material |
High quality carbon steel plate |
| Tank volume |
2.5 tons of water |
| Configuration and performance |
CB10/20 fire pump, PS8/20W fire monitor. |
| Onboard equipment |
Onboard equipment Fire hose, water injection hose, DC water gun, multifunctional water gun, dry powder fire extinguisher, water collector, water separator, suction pipe wrench, rubber hammer, protective belt bridge, above ground fire hydrant wrench, underground fire hydrant wrench, water hose strap, water hose hook, fire axe, fire suction pipe, suction pipe filter, reducer interface |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Dongfeng D6 2.5 ton water tank fire truck
A fire engine, also known as a fire truck,
refers to a vehicle designed and manufactured according to needs, suitable for
firefighters to use, equipped with various fire-fighting equipment or agents,
for firefighting, auxiliary firefighting, or firefighting rescue. It is the
main tool for firefighting and is also the most basic mobile firefighting
equipment.
Water tank fire truck: The fire extinguishing agent equipped on this vehicle is mainly water. It has a large capacity water storage tank, water gun, water cannon, etc., which can be used for extinguishing conventional fire accidents. It can be directly extinguished using a water source, or it can be directly extinguished by absorbing water from the water source. It can also be used to supply water to other fire extinguishing spraying equipment in the fire scene. Suitable for extinguishing general fire accidents, it is a firefighting vehicle regularly used by the public security fire brigade.
Product parameters
