Dongfeng D9 high flow drainage and rescue vehicle
2024-11-20 14:06:07 Source：CLW
Chassis configuration:
(1)Engine:
B6.2NS6B210, Cummins 210hp
(2)Wheelbase:
4500,4700(mm)
(3)Transmission
Type: Fast 8-speed gearbox
(4)Tire models:9.00R20, 6+1spare tire
| Product Name |
Dongfeng D9 high flow drainage and rescue vehicle |
| Gross vehicle weight(Kg) |
10000(Kg) |
| Curb weight(Kg) |
9805,9870(Kg) |
| Number of approved passengers |
2-3 person |
| Wheelbase(mm) |
4500,4700(mm) |
| Overall Dimension(mm) |
7750,8180,8680,8980,9280×2550×3320(mm) |
| Engine brand & model |
B6.2NS6B210, Cummins 210hp |
| Axle Quantity |
2 |
| Transmission Type |
Fast 8-speed gearbox |
| Tire Spec. & size |
9.00R20, 6+1spare tire |
| configuration |
1. High quality cold-rolled steel plate material 2 Fully sealed structure 3. Sound insulation and noise reduction treatment 4 High end aluminum alloy roller shutter 5. Rainproof, fireproof, and rust proof 6. Philips LED interior lighting 7. Engineering warning light with loudspeaker 8. External lighting (optional lifting type) 9. Mobile foam tank 10. Red and white flash lights are equipped on both sides of the car body 10. Four position visual reversing radar 11. Four hydraulic support legs (optional) |
| Standard accessories for flood control vehicles |
one set of 8-piece flood prevention combination, one 30-meter lifeline,one 100-meter lifeline, one life jacket, one lifebuoy |
| Optional accessories for flood control vehicles |
Pile driver, rubber charging boat, portable electric saw, portable cutting machine, portable electric pickaxe, 4-inch gasoline self-priming pump, portable electric shovel |
| Kindly reminder |
The above information is for reference only, and vehicles can be customized according to customer requirements. |
Dongfeng D9 high flow drainage and rescue vehicle
The high flow drainage and rescue vehicle belongs to a specialized operation vehicle. It is a drainage and rescue mobile pump station that installs a generator set in a soundproof and noise reducing compartment to form a noise reduction power station. It integrates drainage equipment and is mounted on the chassis of a second-class vehicle. It is suitable for all-weather outdoor operations and has the characteristics of stable and reliable overall performance, lightweight and practical integrated operation, fast response, high drainage efficiency, diverse and convenient functions, wide range of applications, and high cost-effectiveness.
High flow drainage emergency vehicles are mainly used for urban flood control, agricultural drought resistance, municipal engineering, and emergency drainage.
Product parameter
